ULTRA is reaching new dimensions
Technical Know-How, flexibility and the endeavour to develop solution-oriented products are our brand mark.
„The fusion of these attributes in the field of special control devices does not show such poignancy in almost any other product field “, acc. to the proxy Stefan Bayer.
ULTRA developed a cam shaft measuring system especially for a well-known engine manufacturer, so to enable him to measure work-piece lengths of up to 2500mm in one single clamping, on a measuring bench of 3500mm.
„No other competitor could accomplish the customer’s requirements for the requested dimensions and with the desired functions“, acc. to Stefan Bayer, „this is certainly an essential aspect in the awarding of project – special solutions have become our day-to-day business long time ago!“. Length measurements, position of T-slots and alignment of the support points on the same height are realised with an optical module. The position of cams and support points are measured with a length measuring module, in a tactile way. The angle measuring of the cam position and cam form are determined with a radius module, also in a tactile way. The diameter of the support points is determined with an extended radius module. The control of the position of the clamping hole to the driving hole on the opposite side is realised by a radius module with a pin. Thus the complex requirement profile of our customer could be implemented in one single measuring system, through well-thought-out individual customized solutions.
Multifunctional measuring systems are suitable for almost all rotationally symmetrical components and they replace a multitude of classic hand measuring tools in the manufacturing area. All the measurements can be executed directly in the production area. Inspection room conditions are not necessary. Thus time and production resources shall be saved.
„Customer satisfaction and confidence represent the most important award for our top-quality work. We do not simply develop products but solutions !“ acc. to Stefan Bayer
